Stock ya Chitoliro cha Octal & Kusangika
Octal Pipe yikusazgapo katundu wakukhazikika, kugubuduka mwakusinthasintha, na kuguliska -grade kuti yiwovwire mapaipi, mafakitale, na mapulojekiti ghakuzenga na nyengo zakugomezgeka zakulongozgera. Vinthu ivyo vikulongoreka apa vikulongora umo tikupelekera vinthu; masaizi ghanyake, msinkhu wa makoma, vyakuvwara, na magulu vingaŵikika kwizira mu netiweki yithu. Tonnage yeneco yikukhwaskika na kulemera kwaumaliro.
Chitoliro chachisulo chambura msoko (21.3mm - 406.4mm)
| Yayi. | Kukura (OD × WT) | Giredi / Vinthu | Sitandade | Utali | Unandi (ma pcs) | Kulemera (MT) |
|---|---|---|---|---|---|---|
| 1 | 21.3 × 2.11 | API 5L Gr.B | API 5L / ASME B36.10M | 6 m | 140 | 0.839 |
| 2 | 21.3 × 2.77 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 6 m | 140 | 1.063 |
| 3 | 21.3 × 3.73 | GB/T 8163 20# | GB/T 8163 | 6 m | 120 | 1.164 |
| 4 | 26.7 × 2.41 | API 5L Gr.B | API 5L / ASME B36.10M | 6 m | 130 | 1.126 |
| 5 | 26.7 × 2.87 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 6 m | 130 | 1.316 |
| 6 | 26.7 × 3.91 | GB/T 8163 20# | GB/T 8163 | 6 m | 110 | 1.428 |
| 7 | 33.4 × 2.77 | API 5L Gr.B | API 5L / ASME B36.10M | 6 m | 120 | 1.401 |
| 8 | 33.4 × 3.38 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 6 m | 120 | 1.666 |
| 9 | 33.4 × 4.55 | ASTM A333 Gr.6 | ASTM A333 | 6 m | 95 | 1.722 |
| 10 | 42.2 × 2.77 | API 5L Gr.B | API 5L / ASME B36.10M | 6 m | 110 | 1.593 |
| 11 | 42.2 × 3.56 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 6 m | 110 | 1.982 |
| 12 | 42.2 × 4.85 | GB/T 8163 20# | GB/T 8163 | 6 m | 90 | 2.001 |
| 13 | 48.3 × 3.00 | API 5L Gr.B | API 5L / ASME B36.10M | 6 m | 105 | 1.902 |
| 14 | 48.3 × 3.68 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 6 m | 105 | 2.262 |
| 15 | 48.3 × 5.08 | ASTM A333 Gr.6 | ASTM A333 | 6 m | 80 | 2.409 |
| 16 | 60.3 × 3.20 | API 5L Gr.B | API 5L / ASME B36.10M | 6 m | 100 | 2.704 |
| 17 | 60.3 × 3.91 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 6 m | 100 | 3.241 |
| 18 | 60.3 × 5.54 | GB/T 8163 20# | GB/T 8163 | 6 m | 85 | 3.412 |
| 19 | 73.0 × 4.00 | API 5L Gr.B | API 5L / ASME B36.10M | 6 m | 90 | 3.653 |
| 20 | 73.0 × 5.16 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 6 m | 80 | 3.874 |
| 21 | 73.0 × 7.01 | ASTM A333 Gr.6 | ASTM A333 | 6 m | 65 | 4.223 |
| 22 | 88.9 × 4.06 | API 5L Gr.B | API 5L / ASME B36.10M | 6 m | 80 | 4.207 |
| 23 | 88.9 × 5.49 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 6 m | 80 | 5.524 |
| 24 | 88.9 × 7.62 | GB/T 8163 20# | GB/T 8163 | 6 m | 65 | 5.969 |
| 25 | 101.6 × 4.50 | GB/T 8163 20# | GB/T 8163 | 6 m | 60 | 4.947 |
| 26 | 101.6 × 6.00 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 6 m | 55 | 5.493 |
| 27 | 101.6 × 8.00 | ASTM A333 Gr.6 | ASTM A333 | 6 m | 40 | 5.491 |
| 28 | 114.3 × 4.78 | API 5L Gr.B | API 5L / ASME B36.10M | 6 m | 60 | 5.469 |
| 29 | 114.3 × 6.02 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 8 m | 58 | 7.657 |
| 30 | 114.3 × 8.56 | GB/T 8163 20# | GB/T 8163 | 8 m | 45 | 7.728 |
| 31 | 133.0 × 6.00 | GB/T 8163 20# | GB/T 8163 | 10 m | 55 | 10.883 |
| 32 | 133.0 × 8.00 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 10 m | 45 | 11.333 |
| 33 | 133.0 × 10.00 | ASTM A333 Gr.6 | ASTM A333 | 10 m | 35 | 11.421 |
| 34 | 141.3 × 5.00 | API 5L Gr.B | API 5L / ASME B36.10M | 8 m | 50 | 7.691 |
| 35 | 141.3 × 6.55 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 8 m | 45 | 8.764 |
| 36 | 141.3 × 9.53 | GB/T 8163 20# | GB/T 8163 | 8 m | 36 | 9.374 |
| 37 | 159.0 × 6.00 | GB/T 8163 20# | GB/T 8163 | 10 m | 46 | 11.513 |
| 38 | 159.0 × 8.00 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 10 m | 40 | 11.860 |
| 39 | 159.0 × 10.00 | ASTM A333 Gr.6 | ASTM A333 | 10 m | 30 | 11.494 |
| 40 | 168.3 × 5.00 | API 5L Gr.B | API 5L / ASME B36.10M | 10 m | 55 | 11.470 |
| 41 | 168.3 × 7.11 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 10 m | 40 | 11.974 |
| 42 | 168.3 × 10.97 | ASTM A333 Gr.6 | ASTM A333 | 10 m | 26 | 11.862 |
| 43 | 194.0 × 6.00 | GB/T 8163 20# | GB/T 8163 | 10 m | 32 | 10.789 |
| 44 | 194.0 × 8.00 | API 5L Gr.B | API 5L / ASME B36.10M | 10 m | 30 | 11.260 |
| 45 | 194.0 × 10.00 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 10 m | 26 | 11.055 |
| 46 | 219.1 × 6.35 | API 5L Gr.B | API 5L / ASME B36.10M | 10 m | 40 | 13.015 |
| 47 | 219.1 × 8.18 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 10 m | 32 | 12.716 |
| 48 | 219.1 × 12.70 | GB/T 8163 20# | GB/T 8163 | 10 m | 24 | 12.811 |
| 49 | 245.0 × 8.00 | GB/T 8163 20# | GB/T 8163 | 10 m | 28 | 12.163 |
| 50 | 245.0 × 10.00 | API 5L Gr.B | API 5L / ASME B36.10M | 10 m | 24 | 12.175 |
| 51 | 245.0 × 12.00 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 10 m | 20 | 12.111 |
| 52 | 273.0 × 6.35 | API 5L Gr.B | API 5L / ASME B36.10M | 10 m | 26 | 12.945 |
| 53 | 273.0 × 9.27 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 10 m | 25 | 13.916 |
| 54 | 273.0 × 12.70 | GB/T 8163 Q345B | GB/T 8163 / GB/T 9711 | 10 m | 20 | 13.966 |
| 55 | 299.0 × 8.00 | GB/T 8163 Q345B | GB/T 8163 / GB/T 9711 | 10 m | 20 | 12.980 |
| 56 | 299.0 × 10.00 | API 5L Gr.B | API 5L / ASME B36.10M | 10 m | 18 | 12.692 |
| 57 | 299.0 × 12.00 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 10 m | 15 | 12.405 |
| 58 | 323.9 × 7.10 | API 5L Gr.B | API 5L / ASME B36.10M | 10 m | 18 | 12.255 |
| 59 | 323.9 × 9.53 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 10 m | 18 | 13.085 |
| 60 | 323.9 × 12.70 | GB/T 8163 Q345B | GB/T 8163 / GB/T 9711 | 10 m | 15 | 13.440 |
| 61 | 355.6 × 7.92 | API 5L Gr.B | API 5L / ASME B36.10M | 10 m | 14 | 12.982 |
| 62 | 355.6 × 9.53 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 10 m | 14 | 13.628 |
| 63 | 355.6 × 15.10 | GB/T 8163 Q345B | GB/T 8163 / GB/T 9711 | 10 m | 10 | 13.555 |
| 64 | 377.0 × 8.00 | GB/T 8163 Q345B | GB/T 8163 / GB/T 9711 | 10 m | 12 | 11.058 |
| 65 | 377.0 × 10.00 | API 5L Gr.B | API 5L / ASME B36.10M | 10 m | 10 | 10.800 |
| 66 | 377.0 × 12.00 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 10 m | 10 | 11.287 |
| 67 | 406.4 × 8.00 | API 5L Gr.B | API 5L / ASME B36.10M | 10 m | 10 | 12.057 |
| 68 | 406.4 × 12.70 | ASTM A106 Gr.B | ASME A106 / ASME B36.10M | 10 m | 10 | 13.790 |
| 69 | 406.4 × 16.70 | GB/T 8163 Q345B | GB/T 8163 / GB/T 9711 | 10 m | 8 | 12.896 |
-
Kukura na kukula kwa mtenje kungasinthika mwakuyana na ivyo vikukhumbikwa pa pulojekiti.
-
Kulemera kwaumaliro kukuthemba pa kulemera kwake pambere ŵandatumizge.
-
Kuphimba (kufipa, varnish, galvanized, 3LPE / FBE) na kumalizga (kwambura kuwoneka / kwakukhozga / kwakukhozga) vikusangika pa pempho.
-
Usange kukula kwakukhumbikwa kulije pa mndandanda, chonde fumbani Octal Pipe kuti musange ndondomeko yinyake ya katundu panji yakuguzira.
LSAW (Utali Wakubisika Arc Welded) Chitoliro 406mm - 1422mm
| Yayi. | Kukura (OD × WT) | Giredi / Vinthu | Sitandade | Utali | Unandi (ma pcs) | Kulemera (MT) |
|---|---|---|---|---|---|---|
| 1 | 406.4 × 8.0 | API 5L Gulu B / L245 | API 5L / GB / T 9711 | 12 m | 26 | 24.522 |
| 2 | 406.4 × 10.0 | API 5L X42 / L290 | API 5L / GB / T 9711 | 12 m | 22 | 25.807 |
| 3 | 406.4 × 12.7 | API 5L X52 / L360 | API 5L / GB / T 9711 | 12 m | 20 | 29.592 |
| 4 | 457 × 8.0 | API 5L Gr.B | API 5L / GB / T 9711 | 12 m | 22 | 26.278 |
| 5 | 457 × 10.0 | API 5L x42 | API 5L / GB / T 9711 | 12 m | 22 | 29.485 |
| 6 | 457 × 12.7 | API 5L x52 | API 5L / GB / T 9711 | 12 m | 18 | 28.925 |
| 7 | 508 × 10.0 | API 5L X52 / L360 | API 5L / GB / T 9711 | 12 m | 18 | 30.540 |
| 8 | 508 × 12.7 | API 5L X56 / L390 | API 5L / GB / T 9711 | 12 m | 16 | 30.745 |
| 9 | 508 × 16.0 | API 5L X60 / L415 | API 5L / GB / T 9711 | 12 m | 14 | 31.971 |
| 10 | 559 × 10.0 | API 5L x52 | API 5L / GB / T 9711 | 12 m | 15 | 28.491 |
| 11 | 559 × 12.7 | API 5L x56 | API 5L / GB / T 9711 | 12 m | 15 | 33.892 |
| 12 | 559 × 16.0 | API 5L X60 | API 5L / GB / T 9711 | 12 m | 12 | 30.441 |
| 13 | 610 × 12.7 | API 5L X60 / L415 | API 5L / GB / T 9711 | 12 m | 14 | 35.244 |
| 14 | 610 × 14.3 | API 5L X60 / L415 | API 5L / GB / T 9711 | 12 m | 14 | 39.269 |
| 15 | 610 × 18.0 | API 5L X65 / L450 | API 5L / GB / T 9711 | 12 m | 12 | 37.904 |
| 16 | 660 × 12.7 | API 5L X60 | API 5L / GB / T 9711 | 12 m | 12 | 32.992 |
| 17 | 660 × 16.0 | API 5L X65 | API 5L / GB / T 9711 | 12 m | 12 | 38.974 |
| 18 | 660 × 20.0 | API 5L x70 | API 5L / GB / T 9711 | 12 m | 10 | 36.548 |
| 19 | 711 × 14.3 | API 5L X65 | API 5L / GB / T 9711 | 12 m | 10 | 39.904 |
| 20 | 711 × 16.0 | API 5L X65 | API 5L / GB / T 9711 | 12 m | 10 | 44.185 |
| 21 | 711 × 20.0 | API 5L x70 | API 5L / GB / T 9711 | 12 m | 8 | 38.638 |
| 22 | 762 × 14.3 | API 5L X65 | API 5L / GB / T 9711 | 12 m | 9 | 39.085 |
| 23 | 762 × 18.0 | API 5L x70 | API 5L / GB / T 9711 | 12 m | 9 | 47.231 |
| 24 | 762 × 22.0 | API 5L x80 | API 5L / GB / T 9711 | 12 m | 7 | 45.573 |
| 25 | 813 × 16.0 | API 5L x70 | API 5L / GB / T 9711 | 12 m | 8 | 43.302 |
| 26 | 813 × 20.0 | API 5L x70 | API 5L / GB / T 9711 | 12 m | 6 | 36.421 |
| 27 | 813 × 25.0 | API 5L x80 | API 5L / GB / T 9711 | 12 m | 5 | 37.853 |
| 28 | 914 × 16.0 | API 5L x70 | API 5L / GB / T 9711 | 12 m | 6 | 37.915 |
| 29 | 914 × 20.0 | API 5L x70 | API 5L / GB / T 9711 | 12 m | 6 | 46.776 |
| 30 | 914 × 25.0 | API 5L x80 | API 5L / GB / T 9711 | 12 m | 4 | 35.980 |
| 31 | 1016 × 18.0 | API 5L x70 | API 5L / GB / T 9711 | 12 m | 6 | 41.969 |
| 32 | 1016 × 22.0 | API 5L x80 | API 5L / GB / T 9711 | 12 m | 5 | 40.906 |
| 33 | 1016 × 25.0 | API 5L x80 | API 5L / GB / T 9711 | 12 m | 4 | 33.577 |
| 34 | 1219 × 20.0 | API 5L x70 | API 5L / GB / T 9711 | 12 m | 4 | 34.015 |
| 35 | 1219 × 25.0 | API 5L x80 | API 5L / GB / T 9711 | 12 m | 4 | 41.947 |
| 36 | 1422 × 22.0 | API 5L x70 | API 5L / GB / T 9711 | 12 m | 3 | 26.158 |
| 37 | 1422 × 25.0 | API 5L x80 | API 5L / GB / T 9711 | 12 m | 3 | 29.655 |
| 38 | 1422 × 28.0 | API 5L x80 | API 5L / GB / T 9711 | 12 m | 3 | 33.021 |
-
Kukura na kukula kwa mtenje kungasinthika mwakuyana na ivyo vikukhumbikwa pa pulojekiti.
-
Kulemera kwaumaliro kukuthemba pa kulemera kwake pambere ŵandatumizge.
-
Kuphimba (kufipa, varnish, galvanized, 3LPE / FBE) na kumalizga (kwambura kuwoneka / kwakukhozga / kwakukhozga) vikusangika pa pempho.
-
Usange kukula kwakukhumbikwa kulije pa mndandanda, chonde fumbani Octal Pipe kuti musange ndondomeko yinyake ya katundu panji yakuguzira.
ERW (Yapachanya-Kulimbana na Magesi Kwakukhozgeka) Chitoliro
| Yayi. | Kukura (OD × WT) | Giredi / Vinthu | Sitandade | Pachanya | Utali | Unandi (ma pcs) | Kulemera (MT) |
|---|---|---|---|---|---|---|---|
| 1 | 21.3 × 2.11 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Chifipa | 6 m | 160 | 0.959 |
| 2 | 21.3 × 2.77 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Chifipa | 6 m | 150 | 1.139 |
| 3 | 21.3 × 3.73 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Kukhozgeka | 6 m | 120 | 1.164 |
| 4 | 26.7 × 2.41 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Chifipa | 6 m | 140 | 1.213 |
| 5 | 26.7 × 2.87 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Chifipa | 6 m | 130 | 1.316 |
| 6 | 26.7 × 3.91 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Kukhozgeka | 6 m | 110 | 1.428 |
| 7 | 33.4 × 2.77 | API 5L Gr.B | API 5L / ASME B36.10M | Chifipa | 6 m | 130 | 1.517 |
| 8 | 33.4 × 3.38 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Chifipa | 6 m | 130 | 1.803 |
| 9 | 33.4 × 4.55 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Kukhozgeka | 6 m | 100 | 1.813 |
| 10 | 48.3 × 3.00 | API 5L Gr.B | API 5L / ASME B36.10M | Chifipa | 6 m | 110 | 1.993 |
| 11 | 48.3 × 3.68 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Chifipa | 6 m | 110 | 2.370 |
| 12 | 48.3 × 5.08 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Kukhozgeka | 6 m | 90 | 2.708 |
| 13 | 60.3 × 3.20 | API 5L Gr.B | API 5L / ASME B36.10M | Chifipa | 6 m | 100 | 2.704 |
| 14 | 60.3 × 3.91 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Chifipa | 6 m | 100 | 3.241 |
| 15 | 60.3 × 5.54 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Kukhozgeka | 6 m | 80 | 3.212 |
| 16 | 73.0 × 4.00 | API 5L Gr.B | API 5L / ASME B36.10M | Chifipa | 6 m | 85 | 3.447 |
| 17 | 73.0 × 5.16 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Chifipa | 6 m | 85 | 4.113 |
| 18 | 73.0 × 7.01 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Chifipa | 6 m | 60 | 3.901 |
| 19 | 88.9 × 4.06 | API 5L Gr.B | API 5L / ASME B36.10M | Chifipa | 6 m | 80 | 4.207 |
| 20 | 88.9 × 5.49 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Chifipa | 6 m | 80 | 5.524 |
| 21 | 88.9 × 7.62 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Kukhozgeka | 6 m | 60 | 5.507 |
| 22 | 114.3 × 4.78 | API 5L Gr.B | API 5L / ASME B36.10M | Chifipa | 6 m | 65 | 5.920 |
| 23 | 114.3 × 6.02 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Chifipa | 6 m | 65 | 6.452 |
| 24 | 114.3 × 8.56 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Chifipa | 6 m | 55 | 6.522 |
| 25 | 141.3 × 5.00 | API 5L Gr.B | API 5L / ASME B36.10M | Chifipa | 6 m | 50 | 5.755 |
| 26 | 141.3 × 6.55 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Chifipa | 6 m | 50 | 6.666 |
| 27 | 141.3 × 9.53 | ASTM A53 Gr.B Mtundu wa E | ASTM A53 | Chifipa | 6 m | 40 | 6.437 |
-
Kukura na kukula kwa mtenje kungasinthika mwakuyana na ivyo vikukhumbikwa pa pulojekiti.
-
Kulemera kwaumaliro kukuthemba pa kulemera kwake pambere ŵandatumizge.
-
Kuphimba (kufipa, varnish, galvanized, 3LPE / FBE) na kumalizga (kwambura kuwoneka / kwakukhozga / kwakukhozga) vikusangika pa pempho.
-
Usange kukula kwakukhumbikwa kulije pa mndandanda, chonde fumbani Octal Pipe kuti musange ndondomeko yinyake ya katundu panji yakuguzira.
SSAW (Spiral Yakubisika Arc Welded) Chitoliro
| Yayi. | Kukura (OD × WT) | Giredi / Vinthu | Sitandade | Utali | Unandi (ma pcs) | Kulemera (MT) |
|---|---|---|---|---|---|---|
| 1 | 508 × 8 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 20 | 23.674 |
| 2 | 508 × 10 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 20 | 29.474 |
| 3 | 508 × 12 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 18 | 31.704 |
| 4 | 610 × 8 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 18 | 25.653 |
| 5 | 610 × 10 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 16 | 28.408 |
| 6 | 610 × 12 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 16 | 33.437 |
| 7 | 710 × 8 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 15 | 25.127 |
| 8 | 710 × 10 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 15 | 31.004 |
| 9 | 710 × 12 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 14 | 32.342 |
| 10 | 820 × 10 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 10 | 22.634 |
| 11 | 820 × 12 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 10 | 26.882 |
| 12 | 820 × 14 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 8 | 24.763 |
| 13 | 914 × 10 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 8 | 20.642 |
| 14 | 914 × 12 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 8 | 24.573 |
| 15 | 914 × 14 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 6 | 20.691 |
| 16 | 1016 × 12 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 6 | 23.662 |
| 17 | 1016 × 14 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 6 | 27.434 |
| 18 | 1016 × 16 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 5 | 25.298 |
| 19 | 1219 × 12 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 5 | 25.686 |
| 20 | 1219 × 14 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 5 | 29.676 |
| 21 | 1219 × 16 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 4 | 25.664 |
| 22 | 1422 × 14 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 4 | 28.388 |
| 23 | 1422 × 16 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 4 | 32.337 |
| 24 | 1422 × 18 | API 5L Gr.B | API 5L / SY / T 5037 | 12 m | 3 | 27.690 |
-
Kukura na kukula kwa mtenje kungasinthika mwakuyana na ivyo vikukhumbikwa pa pulojekiti.
-
Kulemera kwaumaliro kukuthemba pa kulemera kwake pambere ŵandatumizge.
-
Kuphimba (kufipa, varnish, galvanized, 3LPE / FBE) na kumalizga (kwambura kuwoneka / kwakukhozga / kwakukhozga) vikusangika pa pempho.
-
Usange kukula kwakukhumbikwa kulije pa mndandanda, chonde fumbani Octal Pipe kuti musange ndondomeko yinyake ya katundu panji yakuguzira.
Viphaso
Satifiketi ya CE
Chikalata cha ISO 9001
Chikalata cha API Q1
Chikalata cha ABS
Chikalata cha AP-5L
Chikalata cha API-5CT
